Description

TS100 is an affordable DC electronic load designed for testing portable electronics. It provides a constant current load for testing voltage regulators. It is ideal for testing liner regulators (LDO), switching DC-to-DC converters, power supply modules, wall adapters, and more.

The TS100 features two LCD displays for input voltage and load current. Each LCD display has green LED back-light. It features four load currant ranges (10A, 1A, 100mA, and 10mA) for wide range of applications. A precision 10-turn knob adjusts the load current from 0 to maximum in the current range. A green LED lit On/Off button turns the load on and off.

Order Information

Electronic Load

Features


Easy to use

Four current ranges: 10A, 1A, 100mA, and 10mA

Fine 100 uA resolution (10mA range)

Low input voltage

Dual LCD display with backlight

Enable/disable button

10-turn current setting

Over-voltage and over-power protection

Reverse polarity protection


Applications


Portable power management devices testing

Switching and linear regulators testing

Power supply modules

Power adapters testing

Constant current source or sink
